WELCOME TO TODAY’S

GENERATION OF

COMFORT

Congratulations! Your new, high-

efﬁciency gas furnace is a sound invest-

ment which will reward you and your

family with years of warm memories

winter after winter.

Not only is your new furnace energy

efﬁcient, it is also extremely reliable.

Spend just a few minutes with this

booklet to learn about the operation

of your new furnace—and the small

amount of maintenance it takes to

keep it operating at peak efﬁciency.

Years went into the development of

your new furnace. Take a little time

now to assure its most efﬁcient opera-

tion for years to come.

MODEL 58PAV

UPFLOW FURNACE

MODEL 58RAV

DOWNFLOW/

HORIZONTAL FURNACE

UPFLOW FURNACE COMPONENTS

Relief Box

Rating Plate

Gas Valve Control Knob or Electric Switch (On/Off)

Gas Valve

Manual Reset Limit Switch

Gas Burner

Flame Sensor

Hot Surface Ignitor

Status LED Light

Blower and Blower Motor

Draft Safeguard Tube and Switch

Gas Manifold

Blower Door Safety Switch

Filter Retainer

Air Filter
