Dimensions are the same for both models with and without Air Flow Sensors installed

UNIT DIMENSIONS - All dimensions in inches (mm)

EACA

ABCDEFG

Inches MM Inches MM Inches MM Inches MM Inches MM Inches MM Inches MM

0020 24-1/4 616 17-7/8 453 20-15/16 531 22-1/2 572 24-7/8 632 7-1/8 181 21-7/16 545

0014 20-1/4 514 13-7/8 352 16-15/16 429 22-1/2 572 24-7/8 632 7 1/8 181 21-7/16 545

2020 24-1/4 616 17-7/8 453 20-15/16 531 19 483 21-3/8 543 7-1/8 181 18-5/8 473

Models
