TECHNICAL SPECIFICATIONS

(Specifications subject to change without notice.)

MODEL NUMBER-EACA 0014 0020 2020

DIMENSIONS (IN) 20 1/4 x 7 1/8 x 24 7/8 24 1/4 x 7 1/8 x 24 7/8 24 1/4 x 7 1/8 x 21 3/8

UNIT COLOR American Sterling American Sterling American Sterling

AIR FLOW SENSOR INSTALLED NO NO YES

ELECTRICAL INPUT 120V, 60 Hz, 1 PH 120V, 60 Hz, 1 PH 240V, 60Hz, 1PH

MAXIMUM RATED AIR FLOW 1400 CFM 2000 CFM 1400 CFM

(2380 m³/hr.) (3400 m³/hr.) (2380 m

MAXIMUM PRESSURE DROP .11 inch w.g. .14 inch w.g. .11 inch w.g.

@1400 CFM @ 2000 CFM @ 1400 CFM

CELL WEIGHT (2 CELLS IN EACH UNIT) 10 lbs. each 12 lbs. Each 9 lbs. Each

(4.45 kg) (5.45 kg) (4.10 kg)

UNIT WEIGHT 32 lbs 36lbs 36 lbs.

(14.6 kg) (16.4 kg) (16.4 kg)

MAXIMUM POWER CONSUMPTION 40 watts 48 watts 40 watts

ELECTRICAL OUTPUT 2.5mADC 3.2 mADC 2.5 mADC

@ 6200 kVDC @ 6200 kVDC @ 6200 kVDC

CLASSIFICATION UL/CUL UL/CUL UL/CUL

³hr.)
