3
CUT ALONG DOTTED LINE CUT ALONG DOTTED LINE
ELECTRICAL DATA
Power Supply to Unit ___________ Volts ________________ Phase _________ Hz
Minimum Circuit Amps ______________ Maximum Overcurrent Protection _______________
SUBMITTAL DATA
Job Name ___________________________________________________________
Architect ____________________________________________________________
Engineer ____________________________________________________________
Contractor ___________________________________________________________
Unit Designation ______________________________________________________
OPTIONS AND ACCESSORIES
FACTORY-INSTALLED OPTIONS
Fully Integrated Gear Driven EconoMi$er with Microprocessor
Controller
Additional 5-Year (6th-10th Year) Extended Protection Plan on the
Heat Exchanger
Four-Year Extended Protection Plan on the Compressor
(020, 025, 028)
Apollo Controls
Service Option Package (Hinged Access Panels, Non-Fused
Disconnect, 115-v Convenience Outlet)
Low/Medium/High Gas Heat
Pre-Coated Condenser Coils
E-Coated Condenser Coils
Stainless Steel Heat Exchangers
High Static Fan Motor
DESIGN ENHANCEMENT CENTER (DEC)
FACTORY OPTIONS
3rd Party Controls (Novar, METASYS, etc.)
Smoke Detectors
Double Wall Construction
Hot Gas Bypass
FIELD-INSTALLED ACCESSORIES
Fully Integrated Gear Driven EconoMi$er with Microprocessor
Controller
Low Ambient Kit — Down to 10 F (016, 020, 028)
Low Ambient Kit — Down to 25 F (025)
Return Air Temperature Sensor (Differential Dry Bulb
EconoMi$er Control)
Solid State Enthalpy Control — Outside Air
Solid State Enthalpy Control with Harness — Return Air
Winter Start Package
Roof Curb (14-in.)
Roof Curb (24-in.)
Roof Curb (Horizontal Supply)
Factory Preassembled, High Static Regain, Horizontal Conversion
Adapter Roof Curb
Additional 5-Year (6th-10th Year) Extended Protection Plan on the
Heat Exchanger
Four-Year Extended Protection Plan on the Compressor
(020, 025, 028)
Power Exhaust
Barometric Relief
Thermostat and Subbase
Time Guard® II Device
Two-Position Damper Package
Motormaster® Control
Liquid Propane (LP) Gas Kit
Hail Guard
CO
2
Sensor — Duct Mount
CO
2
Sensor — Wall Mount
