Carrier Accessories*

* Factory-authorized and field installed. Gas conversion kits are A.G.A./C.G.A. recognized.

S 16 x 25 filters suitable for side return on all furnace sizes.

DESCRIPTION

PART NO. 045-

045-

070-

090-

110-

135-

155-

EZ Flex Media Filter with end

caps – 16 in. (9 pack)

EXPXXUNV0016 XXXXXX X

EZ Flex Media Filter with end

caps – 20 in. (9 pack)

EXPXXUNV0020 X X X X X

EZ Flex Media Filter with end

caps – 24 in. (6 pack)

EXPXXUNV0024 XX

Replacement EZ Flex Filter – 16 in.

(10 pack)

EXPXXFIL0016 XXXXXX X

Replacement EZ Flex Filter – 20 in.

(10 pack)

EXPXXFIL0020 X X X X X

Replacement EZ Flex Filter – 24 in.

(10 pack)

EXPXXFIL0024 XX

Exterior Filter Rack

–

universal, one

inch (adjustable from 14" to 24")

with filter

KGAFR0301ALL

KGAFR0306ALL

(6-pack)

XXXXXXXXXX X X X X

Unframed filter, one inch – 16x25 KGAWF1301UFR

KGAWF1306UFR

(6-pack)

XXXXXXSSXS S S S S

Unframed filter, one inch – 20x25 KGAWF1401UFR

KGAWF1406UFR

(6 pack)

XX X X X

Unframed filter, one inch – 24x25 KGAWF1501UFR

KGAWF1506UFR

(6 pack)

Twinning Kit KGATW0601HSI XXXXXXXXXX X X X X

Combustible Floor Base (not

required when evaporator coil case

is used)

KGASB0201ALL XXXXXXXXXX X X X X

Downflow Vent Guard (not required

when vent is routed through

cabinet)

KGAVG0101DFG XXXXXXXXXX X X X X

Vent Extension Kit (may be used

when vent is routed through cabinet

in downflow)

KGAVE0101DNH

XXXXXXXXXX X X X X

Chimney Adapter Kit - 4 inch vent KGACA02014FC XXXXXXXXXX X

Chimney Adapter Kit - 5 inch vent KGACA02015FC XXX

Natural-to-Propane Gas

Conversion Kit (Single Kit)*

KGANP2901ALL

XXXXXXXXXX X X X X

Propane-to-Natural Gas

Conversion Kit (Single Kit)

KGAPN2301ALL

XXXXXXXXXX X X X X

Gas Orifice Kit (Qty 50) Size 42 KGAHA0150N42

Gas Orifice Kit (Qty 50) Size 43 KGAHA0250N43

Gas Orifice Kit (Oty 50) Size 44 KGAHA0350N44

Gas Orifice Kit (Oty 50) Size 45 KGAHA0450N45

Gas Orifice Kit (Oty 50) Size 46 KGAHA0550N46

Gas Orifice Kit (Oty 50) Size 47 KGAHA1550N47

Gas Orifice Kit (Oty 50) Size 48 KGAHA1850N48

Gas Orifice Kit (Oty 50) Size 54 KGAHA0850P54

Gas Orifice Kit (Oty 50) Size 55 KGAHA0750P55

Gas Orifice Kit (Oty 50) Size 56 KGAHA0850P56

Gas Orifice Kit (Oty 50)1.25 mm KGAHA5750125

Gas Orifice Kit (Oty 50)1.30mw KGAHA5750130

See Installation Instructions for model,

altitude, and heat value usages.
