58MTB

Combustion-air and vent piping for Direct Vent (2-Pipe)

and Non-Direct Vent (1-Pipe) Applications

MAXIMUM ALLOWABLE EXPOSED VENT PIPE LENGTH (FT) WITH AND WITHOUT INSULATION

IN WINTER DESIGN TEMPERATURE AMBIENT*

* Pipe length (ft) speciﬁed for maximum pipe lengths located in unconditioned spaces. Pipes located in unconditioned space cannot exceed total

allowable pipe length as speciﬁed in Table 6.

† Insulation thickness based on R value of 3.5 per inch.

UNIT

SIZE

WINTER DESIGN

TEMPERATURE

(°F)

MAX PIPE

DIAMETER

(IN.)

WITHOUT

INSULATION

WITH 3/8-IN. OR

THICKER INSULATION†

060

20 2 44 70

0 2 21 70

–20 2 20 57

080

20 2 55 55

0 2 30 55

–20 2 16 55

20 2.5 58 70

0 2.5 29 70

–20 2.5 14 67

100

20 2.5 40 40

0 2.5 38 40

–20 2.5 21 40

20 3 63 70

0 3 30 70

–20 3 12 70

120

20 3 70 70

0 3 38 70

–20 3 19 70

20 4 65 70

0 4 26 70

–20 4 5 65
