PSC MOTOR OPTION

LEGEND NOTES:

1. Ground loop heat pump ratings require an extended range option.

2. Rating based upon ANSI/AHRI/ASHRAE/ISO 13256-1 with 1-in. disposable

filt

ECM MOTOR OPTION (Constant Torque)

LEGEND NOTES:

1. Ground loop heat pump ratings require an extended range option.

2. Rating based upon ANSI/AHRI/ASHRAE/ISO 13256-1 with 1-in. disposable

filter.

50PC

UNIT

SIZE

WATER LOOP HEAT PUMP GROUND WATER HEAT PUMP GROUND LOOP HEAT PUMP

CFM GPM

Cooling 86 F Heating 68 F Cooling 59 F Heating 50 F Cooling 77 F Heating 32 F

Capacity

BTU/h

EER

BTU/W-h

Capacity

BTU/h COP

Capacity

BTU/h

EER

BTU/W-h

Capacity

BTU/h COP

Capacity

BTU/h

EER

BTU/W-h

Capacity

BTU/h COP

007

6,100

12.20

7,800

5.30

6,800

15.10

4,900

3.40

300 2.0

009

8,200

12.40

9,900

4.70

8,700

14.60

5,740

3.20

350 2.5

012

10,900

12.20

13,000

4.30

11,800

14.10

8,700

3.20

400 3.0

015

14,200

12.80

16,100

4.40

14,200

14.60

11,300

3.30

500 4.0

018

19,400

13.40

22,200

4.60

21,200

15.80

14,300

3.50

650 5.0

024

23,400

13.40

26,600

4.40

25,000

15.50

17,000

3.40

850 6.0

030

29,200

13.20

33,400

4.30

31,000

14.70

20,900

3.30

950 7.0

036

37,900

14.70

41,800

4.60

39,900

16.90

26,900

3.50

1200 9.0

042

40,000

13.70

46,300

4.30

42,600

14.80

31,000

3.30

1400 10.0

048

45,900

13.00

56,400

4.30

48,800

14.90

35,400

3.40

1600 12.0

060

57,900

13.00

67,200

4.30

60,100

14.10

46,900

3.20

2000 15.0

070

64,000

13.30

72,800

4.40

66,400

15.00

50,800

3.40

2100 16.0

COP — Coefficient Performance

EER — Energy Efficiency Ratio

NA — Not Applicable

50PC

UNIT

SIZE

WATER LOOP HEAT PUMP GROUND WATER HEAT PUMP GROUND LOOP HEAT PUMP

CFM GPM

Cooling 86 F Heating 68 F Cooling 59 F Heating 50 F Cooling 77 F Heating 32 F

Capacity

BTU/h

EER

BTU/W-h

Capacity

BTU/h COP

Capacity

BTU/h

EER

BTU/W-h

Capacity

BTU/h COP

Capacity

BTU/h

EER

BTU/W-h

Capacity

BTU/h COP

015

13,700 13.90 15,500 4.40

14,400 16.20 10,700 3.30

500 4.0

018 19,700 14.40 21,900 4.80 21,500 15.90 14,100 3.70

650 5.0

024 23,800 14.30 26,200 4.60 25,400 16.80 16,700 3.60

850 6.0

030

30,000 15.00 32,800 4.60 31,600 17.50 20,400 3.40

950 7.0

036 38,200 15.40 41,400 4.70 40,200 17.70 26,500 3.60

1200 9.0

042

40,900 14.10 45,300 4.40 43,500 16.30 30,100 3.50

1400 10.0

048 46,800 14.20 55,600 4.50 49,600 16.30 34,600 3.60

1600 12.0

060 59,000 14.30 66,400 4.30 61,100 16.40 46,200 3.30

2000 15.0

070

65,200 14.60 71,800 4.60 67,600 16.60 50,000 3.50

2100 16.0

COP — Coefficient Performance

EER — Energy Efficiency Ratio

NA — Not Applicable

AHRI/ISO capacity ratings
