Cleans the air of smoke, dirt, and

many pollens commonly found.

Saves decorating and cleaning

expenses by keeping carpets,

furniture, and drapes cleaner.

Electronic air cleaner is shown.

CONTROLS:

THERMOSTATS

AND ZONING

Available in programmable and

non-programmable models,

Carrier thermostats maintain a

constant, comfortable tempera-

ture level in the home.

For the ultimate in home com-

fort, Carrier’s 2, 4, and 8 zone

systems allow temperature

control of individual “zones” of

the home. This is accomplished

through a series of electronic

dampers and remote room

sensors. The 4-zone system is

shown.

ENERGY/HEAT

RECOVERY

VENTILATOR

Carrier’s energy or heat recovery

ventilators exhaust stale indoor

air and provide fresh outdoor air

to the home while minimizing

heat loss and humidity level.

Especially useful for today’s

tighter constructed houses.

Energy recovery ventilator is

shown.

HUMIDIFIER

By adding moisture to winter-

dry air, a Carrier humidifier can

often improve comfort and keeps

woodwork, wallpaper, and paint

in better condition. Moisturizing

household air also helps to retain

normal body heat and provides

comfort at lower temperatures.

®

COMBUSTION CHAMBER/

HEAT EXCHANGER

CONTROL CENTER
