Product

Data

58PAV

High-Efficiency

Induced-Combustion

Upflow Furnace

Input Capacities:

45,000 thru 155,000 Btuh

80% AFUE At Budget Price

Carrier provides an 80% Annual

Fuel Utilization Efficiency (AFUE)

gas furnace for the budget conscious

consumer and builder. The 58PAV

offers the same high quality you

demand and receive from Carrier.

The cabinet is constructed from a

specially selected galvanized steel.

There is also double protection for the

cabinet. First, a galvanized steel

substrate provides resistance to rusting.

Then the cabinet is constructed of

prepainted steel — the same high-

quality finish found on refrigerators

and dishwashers.

The 58PAV offers a hot surface

ignition system which provides a

superior and more reliable ignition

system than older spark relight

systems.

The heat exchangers are

constructed of aluminized steel and

covered by a 20-year Limited

Warranty. They are Carrier’s

patented Super-S heat exchangers

that improve heat transfer and enable

downsizing of this furnace to only

40-in. tall.

To improve the sound level, we

have incorporated a soft mount

inducer assembly and a slow opening

gas valve.

The control board is the brain of

this induced-combustion gas furnace.

It offers a unique self-test feature

that checks all the major functions of

the furnace within 1 minute. The

control board also features a 3-amp

fuse that protects the transformer

and control board. Another feature

on the control board is a LED status

indicator light to ensure top furnace

performance.

1 2 3 4 5 6 7 8

Summary of Contents

Page 1 - Upflow Furnace

Page 2 - Model number nomenclature

2 ® ama CANADIAN GAS ASSOCIATIONAPPROVEDR Model number nomenclature 58PAV 045Induced-CombustionUpflow FurnaceInput Capacity 045 — 44,000 Btuh 1

Page 3

3 NOTE: The 58PAV Furnaces are for use with natural gas. These furnaces can be field-converted for propane gas with a factory-authorized and listed

Page 4 - Physical data

4 Carrier accessories* * Factory-authorized and field installed. Gas conversion kits are A.G.A. recognized.† 16 and 20 sizes only. Physical data * Ga

Page 5 - Dimensions

5 Dimensions CLEARANCES (In.) *The 3-in. front clearance is needed for combustion-air and ventilation-air entry. UNIT SIZE 045 AND 070 090—155Sides —

Page 6 - Performance data

6 Performance data PSC—Permanent Split Capacitor ENERGY EFFICIENCY * Capacity and AFUE in accordance with U.S. Government DOE test procedures.ICS—Iso

Page 7 - Typical wiring schematic

7 Typical wiring schematicElectrical data * Length shown is as measured 1 way along wire path between unit and service panel for maximum 2% voltage d

Page 8 - Typical installations

Carrier Corporation • Syracuse, New York 13221 3-96Manufacturer reserves the right to discontinue, or change at any time, specifications or design
