MODEL NUMBER NOMENCLATURE

58UVB

--- --- ---

100

Deluxe Upflow only

V a r i a b l e --- S p e e d D i r e c t --- V e n t ( 2 --- P i p e ) a n d

Condensing Gas Furnace

Series

Input Rates

060 --- 60,000 Btuh

080 --- 80,000 Btuh

100 --- 100,000 Btuh

120 --- 120,000 Btuh

060

Cooling Airflow

(400 CFM per 12,000 Btuh)

14 --- 1400 CF M

20--- 2000CFM

CARRIER ACCESSORIES

DESCRIPTION PART NO.

UNIT SIZE

060---14 080--- 14 080--- 20 100---20 120--- 20

Vent Termination Kit (Bracket Only for 2 Pipes)

2---in. — KGAVT0101BRA

3---in. — KGAVT0201BRA

X X X X X

Concentric Termination Kit (Single Exit)

2---in. — KGAVT0701CVT

3---in. — KGAVT0801CVT

X X X X X

Condensate Freeze Protection Kit KGAHT0101CFP X X X X X

Germicidal Air Purifier Model GAPA X X X X X

Condensate Neutralizer Kit (obtained thru RCD)

P908---0001

X X X X X

Electronic Air Cleaner Model EACA X X X X X

Mechanical Air Cleaner

Model FILCAB or

EZXCAB

X X X X X

Humidifier Model HUM X X X X X

Heat Recovery Ventilator Model HRV X X X X X

Energy Recovery V entilator Model ERV X X X X X

UV Lights Model UVL X X X X X

E Z F l e x M e d i a F i l t e r w i t h e n d c a p s --- 1 6 --- i n . ( 9 p a c k ) EXPXXLMC0016 X

E Z F l e x M e d i a F i l t e r w i t h e n d c a p s --- 2 0 --- i n . ( 9 p a c k ) EXPXXLMC0020 X X X

E Z F l e x M e d i a F i l t e r w i t h e n d c a p s --- 2 4 --- i n . ( 6 p a c k ) EXPXXLMC0024 X

R e p l a c e m e n t E Z F l e x F i l t e r --- 1 6 --- i n . ( 1 0 p a c k ) EXPXXFIL0016 X

R e p l a c e m e n t E Z F l e x F i l t e r --- 2 0 --- i n . ( 1 0 p a c k ) EXPXXFIL0020 X X X

R e p l a c e m e n t E Z F l e x F i l t e r --- 2 4 --- i n . ( 1 0 p a c k ) EXPXXFIL0024 X

E x t e r i o r F i l t e r R a c k --- U n i v e r s a l , 1 --- i n . ( a d j u s t a b l e f r o m 1 4 --- i n . t o

2 4 --- i n . ) w i t h f i l t e r

KGAFR0301ALL

KGAFR0306ALL (6 pack)

X X X X

Unframed Filter 1---in. — 16 x 25

KGAWF1301UFR

KGAWF1306UFR (6 pack)

X S S S

Unframed Filter 1---in. — 20 x 25

KGAWF1401UFR

KGAWF1406UFR (6 pack)

X X X

Unframed Filter 1---in. — 24 x 25

KGAWF1501UFR

KGAWF1506UFR (6 pack)

58UVB
