«6»

CLEARANCES FOR SERVICE AND AIRFLOW,

ALLOW 6 IN. ABOVE UNIT.

T

6 IN.

H

HORIZONTAL AIR

DISCHARGE

HIGH VOLTAGE

1-1/8' DIA.

F1^ © T ¥ f:

[^¡©[Hlir ®DlS)i WOiW

UNIT

WEIGHT

A

B

C

38HD018 (67 1 kg) 148 lbs

(329)

r-1"

(15 88) %"

(9 53) %"

38HD024

(72 6 kg) 160 lbs

(329)

r-1"

(15 88) %"

(9 53) %"

38HD030

(77 6 kg) 171 lbs

(329)

r-1"

(15.88) %"

(9.53) %"

NOTES

1 Dimensions in [ ] are in millimeters

2 Air Direction

3. Center of Gravity ^

4 Footprint 018-030, 3 7 sq ft ( 34 m*)

Fig. 2 — 38HD Dimensional Drawing, 018-030
