ARI* capacity ratings

See Legend and Notes on page 6.

UNIT 48TF

NOMINAL

TONS

STANDARD

CFM

NET COOLING

CAPACITY

(Btuh)

TOTAL

SEER† SOUND

RATING

(Bels)

Belt Drive Direct Drive

004

3 1200 35,000 4.0 10.0 9.7 8.1

005

4 1600 47,000 5.5 10.0 9.7 8.1

006

5 2000 57,000 6.7 10.0 9.7 8.1

Model number nomenclature

Nominal Capacity

004 – 3 Tons 008 – 7 1/2 Tons

005 – 4 Tons 009 – 8 1/2 Tons

006 – 5 Tons 012 – 10 Tons

007 – 6 Tons 014 – 12 1/2 Tons

Factory-Installed Option Code*

48 TF E 004 Z — — 5 0 1 DA

48 – Electric Cooling/

Gas Heat

TF – Constant Volume

V-Ph-Hz

1 – 575-3-60

3 – 208/230-1-60†

5 – 208/230-3-60

6 – 460-3-60

Packaging

1 – Domestic

3 – Export

Design Series

0 – Original

Factory-Installed Communicating Controls

–– Standard. No Hinged Access Panels

P – Carrier PremierLink™ Rooftop Controller

K – Novar ETM2024 Control

N – Novar ETM3051 Control

Z – Apollo Control

For more information about the Novar Control option,

check with your sales representative.

Coil Fin Option

–– Al Evaporator, Al Condenser

B – Cu Evaporator, Cu Condenser

C – Al Evaporator, Cu Condenser

F – E-Coated Aluminum Condenser Fins

Condenser Coil, Al Evaporator

V – Pre-coated Aluminum

Condenser-Coil Fins

Standard California Compliant

Low NOx 3 Phase

D – Low Heat L – Low Heat G – Low Heat

(low NOx) Single Stage

E – Medium Heat/ M – Medium Heat (3 phase)

High Heat (low NOx) H – Medium Heat Single

F – High Heat N – High Heat Stage (3 phase)

(low NOx) K – High Heat Single

Stage (3 phase)

Indoor Fan Motor

––Standard Motor

A – Alternate Fan Motor

M – High-Static Motor**

LEGEND

AL —

Aluminum

CU —

Copper

FIOP —

Factory-Installed Option

*Refer to 48TF Price Pages for 48TF FIOP code table or contact your

local representative for more details.

†Single phase is only available on 5-ton and smaller units.

**High-static motors are not available for single-phase units and size

014 units.
